Thermo Scientific Nicolet iS20 FTIR Spectrometer

Thermo Scientific Nicolet iS20 FTIR Spectrometer

Get a Price/Quote

Product Details:

Model No Nicolet iS20
Core Components Interferometer, IR source, detector, beam splitter, sample compartment
Frequency Optical resolution up to 0.5 cm
Power Source 220240 V AC, 50/60 Hz
Automation Grade Automatic functions for background, diagnostics, and validation
Feature Automatic atmospheric suppression, validated performance
Voltage 220240 V AC
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Thermo Scientific Nicolet iS20 FTIR Spectrometer Price And Quantity

Thermo Scientific Nicolet iS20 FTIR Spectrometer Product Specifications

Dimension (L*W*H) 50.3 x 39.4 x 22.7 cm
Model No Nicolet iS20
Core Components Interferometer, IR source, detector, beam splitter, sample compartment
Power Source 220240 V AC, 50/60 Hz
Frequency Optical resolution up to 0.5 cm
Automation Grade Automatic functions for background, diagnostics, and validation
Weight ~18 kg
Usage Quantitative and qualitative chemical analysis
Display Type Color touchscreen display
Type FTIR Spectrometer
Feature Automatic atmospheric suppression, validated performance
Equipment Materials Robust metal housing with chemical-resistant coatings
Accuracy Certified wavelength accuracy: better than 0.01 cm
Voltage 220240 V AC
Measurement Range 7800350 cm
Temperature Range Ambient to 50C (spectrometer); compatible with temperature-controlled accessories
Capacity Single sample analysis (expandable with autosampler)

Max Number of Users Multi-user capable with password protection
Software OMNIC Software Suite
Maintenance Tool-free user access, easy maintenance design
Noise Level < 8.0 x 10 Abs (peak-to-peak, 1-minute, 1600 cm)
Resolution Up to 0.5 cm
Detector DTGS (Deuterated Triglycine Sulfate); optional MCT available
Environmental Conditions 1535C, 2080% RH (non-condensing) operating range
Sample Compartment Standard open-architecture; accepts a wide range of accessories
Lamp Life IR source typically 510 years
Optical System Precision-aligned, field-proven interferometer
Spectral Range Standard: 7800350 cm (extendable with optional detectors)
Atmospheric Compensation Built-in automatic suppression of CO and HO
Operating Humidity up to 80% RH, non-condensing
Laser Source Internal reference HeNe or diode laser
Data Interface USB, Ethernet

Product Description

Brand Thermo Fisher Scientific

Model iS20

Capacity 0.25 cm-1 spectral resolution

CAT No iS20

Application Spectroscopy

Maximize laboratory productivity and quickly collect high-quality spectral data with the Thermo Scientific Nicolet iS20 FTIR Spectrometer. An integrated touch panel allows users of any skill level to quickly analyze challenging samples and a multi-color LED scan bar gives users immediate feedback on whether the instrument is in idle, collect, or alert mode. Identify unknown contaminants, perform failure analysis, and accurately analyze mixtures using the spectral power of the built-in Thermo Scientific LightDrive Optical Engine. A 10-year warranty on the

Advanced Analytical Performance

The Nicolet iS20 offers high-resolution capabilities with up to 0.5 cm1 optical resolution and certified wavelength accuracy better than 0.01 cm1. Its field-proven interferometer and automatic atmospheric suppression ensure consistent, reliable results across various sample types. The instrument's robust metal housing and chemical-resistant coatings protect it in demanding laboratory environments.

Intuitive Operation with OMNIC Software

The integrated OMNIC Software Suite simplifies FTIR operation, from sample measurement to data interpretation. Automated background, diagnostic, and validation functions enhance productivity while reducing typical sources of error. Multi-user support and password protection enhance security for laboratory teams.

Flexible Sampling and Accessory Options

A standard open-architecture sample compartment allows compatibility with a wide assortment of accessories, expanding the spectrometer's application range. Temperature-controlled accessories and optional autosamplers further increase flexibility for diverse analytical workflows.

FAQ's of Thermo Scientific Nicolet iS20 FTIR Spectrometer:

Q: How does the automatic atmospheric compensation feature enhance measurement accuracy?

A: The built-in atmospheric compensation automatically suppresses interference from CO2 and H2O vapors during analysis, producing cleaner spectra and more accurate results without additional sample preparation steps.

Q: What sample types and accessories are compatible with the Nicolet iS20 FTIR Spectrometer?

A: The open-architecture sample compartment is compatible with a broad range of sample holders and temperature-controlled accessories, supporting analysis of solids, liquids, and gases. This flexibility makes it suitable for diverse research and industrial applications.

Q: When is maintenance required for the Nicolet iS20 and how is it performed?

A: Routine maintenance is simplified by the tool-free user access design, allowing users to perform basic upkeep without specialized tools. The IR source has a typical lifespan of 5-10 years, reducing replacement frequency and downtime.

Q: Where can the Nicolet iS20 FTIR Spectrometer be installed, and what are its environmental requirements?

A: The spectrometer operates reliably within temperatures of 15-35C and humidity levels of 20-80% (non-condensing). Its robust construction and moderate size (~18 kg, 50.3 x 39.4 x 22.7 cm) make it suitable for most analytical laboratories in India.

Q: What process does the OMNIC Software facilitate during FTIR analysis?

A: OMNIC Software manages the entire analysis process, including instrument background measurements, sample analysis, diagnostic checks, and data validation. This automation reduces operator workload and increases analytical throughput.

Q: What benefits does multi-user capability provide in laboratory settings?

A: Multi-user capability with password protection ensures secure, individualized access for multiple users, supporting collaborative work while maintaining data privacy and instrument integrity.
