Mettler Toledo pH Sensor InPro3100/120/PT100

Mettler Toledo pH Sensor InPro3100/120/PT100

Get a Price/Quote

Product Details:

Model No InPro3100/120/PT100
Accuracy 0.01 pH
Feature Integrated Pt100 temperature sensor, autoclavable, pressurized reference
Core Components Glass Electrode, Reference System, PT100 Temperature Sensor
Temperature Range 0 to 100C
Automation Grade Manual/Automatic, compatible with automatic systems
Power Source None (Passive Sensor)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Mettler Toledo pH Sensor InPro3100/120/PT100 Price And Quantity

Mettler Toledo pH Sensor InPro3100/120/PT100 Product Specifications

Feature Integrated Pt100 temperature sensor, autoclavable, pressurized reference
Temperature Range 0 to 100C
Core Components Glass Electrode, Reference System, PT100 Temperature Sensor
Model No InPro3100/120/PT100
Equipment Materials Glass Electrode, Stainless Steel Body
Type pH Sensor
Weight Approx 350 g
Accuracy 0.01 pH
Usage Measurement of pH in industrial processes
Measurement Range pH 0 14
Automation Grade Manual/Automatic, compatible with automatic systems
Power Source None (Passive Sensor)
Dimension (L*W*H) Length: 120 mm, Diameter: 12 mm

Application Inline measurement and control
Autoclavable Yes
Temperature Compensation Pt100
Response Time < 15s (to reach 95% value)
IP Protection Class IP68
Sensor Length 120 mm
Sensor Diameter 12 mm
Pressure Range Max 13 bar (at 25°C)
Cable Connection S8 connector
Cleaning Method Steam sterilization compatible
Reference System Type Silver/Silver Chloride
Operating Environment Industrial, Pharma, Food & Beverage applications
Sensor Material Glass, Stainless Steel
Connector Type S8 plug head

Product Description

Brand Mettler Toledo

Model InPro

Capacity 0 14 pH

CAT No 52000656

Application Inprocess Analysis

The InPro 3100 is a pH electrode with temperature sensor, designed for measurement in bioprocesses where CIP and SIP procedures are required. The 120 mm version is optimal for short installation lengths.

Precision Designed for Demanding Applications

Crafted with a rugged glass electrode and stainless steel body, the InPro3100/120/PT100 is built to withstand rigorous industrial processes. Its precise measurement range (pH 0-14) and accuracy of 0.01 pH make it a reliable choice for pharmaceutical, food & beverage, and chemical industries. The sealed reference system enhances stability, reducing drift and maintaining consistent performance under varying process conditions.

Versatile Integration and Easy Maintenance

The sensor supports both manual and automatic operations and connects effortlessly to process systems via its S8 plug head. With IP68 protection and autoclavable materials, the InPro3100/120/PT100 ensures longevity in harsh process environments. Routine maintenance is simplified by its steam sterilization compatibility, helping users maintain high hygiene standards efficiently.

FAQ's of Mettler Toledo pH Sensor InPro3100/120/PT100:

Q: How does the InPro3100/120/PT100 sensor compensate for temperature variations during pH measurement?

A: The sensor includes an integrated Pt100 temperature sensor, which ensures accurate temperature compensation during pH measurement. This allows precise readings even when the process temperature changes, with a rapid response time of under 15 seconds.

Q: What is the maximum pressure and temperature this pH sensor can withstand?

A: The InPro3100/120/PT100 can operate at pressures up to 13 bar (at 25C) and in temperatures ranging from 0 to 100C, making it suitable for demanding process environments commonly found in industrial, pharmaceutical, and food & beverage applications.

Q: When and where should this sensor be used in industrial processes?

A: This sensor is ideal for inline measurement and control of pH levels in continuous process flows. It is widely applied in sectors requiring consistent monitoring, such as chemical manufacturing, pharmaceuticals, and food & beverage processing plants across India.

Q: What are the core components of the InPro3100/120/PT100 pH sensor?

A: The main components include a glass electrode for pH detection, a Silver/Silver Chloride reference system, and an integrated Pt100 temperature sensor, all encased in a glass and stainless steel body for durability.

Q: How is the sensor cleaned and maintained?

A: The InPro3100/120/PT100 is designed for easy maintenance; it is autoclavable and compatible with steam sterilization, ensuring reliable sanitation and longevity in applications requiring stringent hygiene.

Q: What connectivity options does this pH sensor offer for integration with automation systems?

A: It is equipped with an S8 plug head, allowing seamless connection to various transmitters and process control systems, and supports both manual and automatic operation modes.

Q: What benefits does using the InPro3100/120/PT100 provide for process optimization?

A: It offers high measurement accuracy (0.01 pH), rapid response, easy integration, robust durability, and steam-sterilization compatibility. These features help optimize process control, ensure product quality, and reduce maintenance downtime.
