Qiagen EZ2 Connect Fx System

Get a Price/Quote

Product Details:

Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Qiagen EZ2 Connect Fx System Price And Quantity

Product Description

Brand Qiagen

Model EZ2

Capacity 24 Sample

CAT No 9003220

Application Molecular Biology

Meet your labas need for increased throughput, reproducibility and flexibility with the EZ2 Connect Fx. This benchtop instrument automates processing of up to 24 samples at a time in around 20 minutes using the EZ1 Advanced XL magnetic-bead purification technology you know and trust. Easily access a variety of dedicated human ID and forensics protocols at the push of a button and isolate high-quality DNA for numerous downstream applications from a wide range of sample types, such as cigarette butts, saliva, blood, touch samples, bone and semen. Benefit from the EZ2 Connect Fxas flexibility in the sample input and elution volumes, with protocols allowing up to 2 mL of input lysate and elution volumes ranging from 20 AL a 200 AL. Plus, with its remote connectivity feature, you can monitor your runs and manage your instrument even from outside the lab.

Advanced Automation for Forensic Laboratories

The EZ2 Connect Fx System streamlines DNA/RNA extractions for forensic workflows, requiring minimal manual intervention. Compatible with a diverse range of biological samples, the system provides consistent, reproducible results and supports real-time protocol selection through an intuitive touchscreen interface. With HEPA filtration and UV decontamination, laboratories benefit from heightened biosafety and contamination prevention.

Flexible and User-Friendly Operation

This instrument supports both barcode scanning and username/password logins for secure sample tracking. It operates efficiently in various environments ranging from 15-30C and 20-80% relative humidity. The 7-inch color touchscreen offers straightforward navigation in multiple languages, including English and German, making the system accessible to a diverse user base across India.

FAQ's of Qiagen EZ2 Connect Fx System:

Q: How does the Qiagen EZ2 Connect Fx System automate DNA/RNA extraction processes?

A: The system fully automates the extraction process using pre-programmed protocols and disposable reagent cartridges. Once samples are loaded, users simply follow instructions on the touchscreen, and the system handles the entire workflow, including lysis, binding, washing, and elution.

Q: What sample types and volumes can be processed with this instrument?

A: The EZ2 Connect Fx System supports multiple sample types such as blood, swabs, and tissue, processing volumes ranging from 200 L to 5 mL. This flexibility allows laboratories to handle a wide variety of forensic specimens in one instrument.

Q: When should the internal decontamination process with the UV lamp be used?

A: Internal UV decontamination should be carried out after each run to minimize cross-contamination, especially when processing high-risk or sensitive forensic samples. The ultraviolet lamp ensures the internal chamber is sterilized efficiently before the next use.

Q: Where can this system be installed, and is it portable?

A: Designed for benchtop use, the EZ2 Connect Fx System fits standard laboratory benches. While it's not wall-mountable, its semi-portable design allows for easy movement within the lab if needed.

Q: What security and safety features are included in the EZ2 Connect Fx System?

A: Security is managed via barcode scanning and username/password logins. Safety features include a HEPA filter, UV sterilization, LED operation status indicators, auto-stop upon door opening, and liquid level sensors to ensure safe, reliable operation.

Q: How does the system enable data integration and synchronization with external platforms?

A: The instrument is equipped with USB and Ethernet ports for data transmission. It offers compatibility with Q-Base and laboratory information management systems (LIMS), facilitating easy data transfer and synchronization across laboratory networks.
